Series No.: HC-MP722-01XXG0ZX101X01

Description: 1.27mm Machined Pin Header H2.2 Single Row L=10.1mm Right Angle SMT Type

Position:  1x02P TO 1x50

Type: Right Angle SMT

Package : PE Bag/ Tube or Tape&Reel Packing

MOQ: 1K

Free samples:10pcs within 1 weeks.

Specifications

Rated Current:1.0 AMP

Mechanical Life：500 Cycles Min

Contact Resistance: 10mΩ  Max

Withstand Voltage:500V AC/DC

Insulation Resistance:1000mΩ Min

Operation Temperature: -40°c to +105°c

Contact Material：Brass

Contact Plating：Au or SN  Over Ni

Insulator Material: PPS-GF30-FR-UL94V-0
