1.27mm Machined Pin Header H2.2 Single Row L=10.1mm Right Angle SMT Type
HC-MP722-01XXG0ZX101X01
EXW,FOB
500 pieces
500000pieces / Month
China
15Day
HC-MP722-01XXG0ZX101X01
Quantity
1.27mm Machined Pin Header H2.2 Single Row L=10.1mm Right Angle SMT Type
Series No.: HC-MP722-01XXG0ZX101X01
Description: 1.27mm Machined Pin Header H2.2 Single Row L=10.1mm Right Angle SMT Type
Position: 1x02P TO 1x50
Type: Right Angle SMT
Package : PE Bag/ Tube or Tape&Reel Packing
MOQ: 1K
Free samples:10pcs within 1 weeks.
Specifications
Rated Current:1.0 AMP
Mechanical Life：500 Cycles Min
Contact Resistance: 10mΩ Max
Withstand Voltage:500V AC/DC
Insulation Resistance:1000mΩ Min
Operation Temperature: -40°c to +105°c
Contact Material：Brass
Contact Plating：Au or SN Over Ni
Insulator Material: PPS-GF30-FR-UL94V-0
