Pin header connector is widely used in electronic, electrical, instrument and other PCB circuit board connector. It can not only be used with the connector to form board to board connection, but also can be used with the electronic wire harness terminal to form board to line connection, can also be used alone for board to board connection. Hence the reputation of the universal connector. Due to the wide application, there are a variety of models and specifications of the row pin connector, and we must pay attention to the accurate selection when choosing.

1. Common spacing of Pin header includes 0.8mm, 1.0mm, 1.27mm, 2.0mm, 2.54mm, 3.96mm, 5.08mm spacing.

2. The number of pin header rows can be divided into single row, double row, three row, four row, etc.

3. According to the pin header size classification, the needle row can be divided into straight , Right Angle, SMT.

4. The size of the pin header can be determined according to the external dimension of length, width, thickness and row distance.

5. Pin header according to the installation Angle including 180° vertical, 90°, 100°.
